BS 6853 Annex D/smoke density/BS 6853
BS 6853 Annex D: Methods for measuring smoke density
The smoke density measurement taken from a material under fire conditions gives an indication of the visibility
through the smoke, this is important as reduced visibility in a real fire situation makes it more difficult to
escape from a fire hence increasing the threat to human life from the toxic gases, flames and heat.
There are five different test methods which can be utilized to determine the smoke density produced from
materials to be placed on passenger carrying trains in the UK.
The five different methods are as follows:
BS 6853 Annex D.8.3 – small scale test method
BS 6853 Annex D.8.4 – panel test method
BS 6853 Annex D.8.5 – seat test method
BS 6853 Annex D.8.6 – floor test method
BS 6853 Annex D.8.7 – cable test method
BS 6853 Annex D.8.3 is utilized for minor use materials (Tables 7 and 8 of BS 6853: 1999) and textiles (Table
11 of BS 6853: 1999).
BS 6853 Annex D.8.4 is utilized for interior and exterior vertical surfaces and horizontal prone surfaces
(Tables 2, 3, 5 and 6 of BS 6853: 1999) and seat shell (table 10 of BS6853: 1999).
BS 6853 Annex D.8.5 is utilized for seats (Tables 9 of BS6853: 1999).
BS 6853 Annex D.8.6 is utilized for interior and exterior horizontal supine surfaces (Tables 1 and 4 of BS
6853:1999) and mattresses (table 12 of BS 6853: 1999).
BS 6853 Annex D.8.7 is utilized for interior and exterior cables (Tables 13 and 14 of BS 6853: 1999).
The test is performed inside a chamber measuring 3 metres by 3 metres by 3 metres and the test is sometimes
referred to as the three metres cube test. The test duration is 40 minutes.
Application BS 6853 Annex D Fire testing materials
Rubber product、rubber seal
Ceiling covering
Walling covering
Textile、curtain、adumbral product、Non-woven fabrics
Seat shell、seat trim
Flooring covering
Foam material、sponge、melamine foam
Paint、adhesives、pigment、varnish
FRP、FPP composite materials、SMC sheet
Adhesives、glue
Window、door and framework
Small parts
Connector、connected equipment
Pipe、cooling pipe、heat pipe
Other materials
