Cable testing for EN45545-2:2010/EN 50268-2/EN 61034-2
EN 45545-2 Railway applications-Fire protection on railway vehicles Part 2: Requirements for fire behaviour of materials and components.
EN 45545-2 according to the product end-use, divided into R1-R26 level, R14-Interior cable, R15-Exterior cable.
As the cable flame spread and burning rate of destruction of the length of the combustion smoke density (light penetration) and the burning of hazardous toxic gas escape on the staff of life play a very important influence. In general, testing cables through these areas to assess.
Cable testing standard for EN45545-2:2010
BS EN 50266-2-4: Common test methods for cables under fire conditions - Test for vertical flame spread of vertically-mounted bunched wires or cables - Procedures - Category C (cable diameter ≥12mm)
BS EN 50266-2-5: Common test methods for cables under fire conditions - Test for vertical flame spread of vertically-mounted bunched wires or cables - Procedures - Category D (cable diameter ＜12mm)
EN 50306 Section 9.1.1: Railway applications-Railway rolling stock cables having special fire performance-thin wall (6mm＜cable diameter＜12mm)
EN 50306 Section 9.1.2: Railway applications-Railway rolling stock cables having special fire performance-thin wall (cable diameter≤6mm)
DIN EN 60332-1-2: DIN EN 60332-1-2: Tests on electric and optical fibre cables under fire conditions—Part 1-2: Test for vertical flame propagation for a single insulated wire or cable—Procedure for 1 KW pre-mixed flame and is for general use
EN 61034-2: smoke density
EN 50268-2: smoke density
NF X 70-100 600℃ CIT cable: toxicity testing
、、、、、、
CEN/TS EN45545
CEN/TS EN45545-Fire protection of railway vehicles
CEN/TS EN45545-1 Part1:Gerneral
CEN/TS EN45545-2 Part2:Requirements for fire behaviour of materials and components
CEN/TS EN45545-3 Part3:Fire resistance requirement for fire barriers and partitions
CEN/TS EN45545-5 Part5:Fire safety requirements for electrical equipment including that of trolley buses, track guided and magnetic levitation vehicles
CEN/TS EN45545-6 Part 6:Fire control and management system
CEN/TS EN45545-7 Part7:Fire safety requirements for flammable liquid and flammable gas installations
